Bike Description for

HUSQVARNA VITPILEN 401

Svartpilen 401

The Svartpilen 401 makes no excuses about its rugged appeal. It is by definition a motorcycle at home on the fringes of a metropolitan playground, where the blacktop is less than perfect. Making use of its lightweight and punchy engine to navigate side streets, it is a master of all it surveys.

01. The Specs

The Specs

ENGINE & GEARBOX

The Svartpilen 401 is powered by a modern 373cc single-cylinder engine that is remarkably compact. With 37Nm of torque from low down in the RPM range and a 6-speed gearbox, it is perfect for urban riding. The electronic fuel injection is operated by a ride-by-wire system and delivers a controlled and refined power. With a peak horsepower of 32 kW (44 hp), the SVARTPILEN is accessible to a wide variety of riders, while its lightweight construction means the power-to-weight ratio will also excite more experienced riders. For added convenience, the gearbox is linked to an easy shift sensor which allows the rider to make seamless up and down shifts without the use of the clutch. The sensor works by relaying the moment the rider actuates the gear lever to the ECU which in turn matches engine parameters to allow a simple gear change at any RPM or engine load.

FRAME

The trellis frame is central to the Svartpilen 401 character and agility. Made from high strength chromium molybdenum steel using hydro formed tubes and robot welding, the frame is not only strong..

BRAKES

The Svartpilen 401 is fitted with hydraulic ByBre brake callipers, which are manufactured to the highest standards, and in combination with 320mm front and 230mm rear perforated steel discs,..E

SUSPENSION

The WP suspension on the Svartpilen 401 is made to exacting standards, ensuring the highest level of quality and craftsmanship. The front suspension features 43 mm open cartridge forks,

EXTERIOR

Reduced to an authentic mix of classic thinking and modern design. This Svartpilen 401 is synonymous with the Swedish heritage of Husqvarna Motorcycles. The lightweight and narrow bodywork is shaped into the Svartpilen 401’s design and intelligently allows for seamless movement while riding. Its dark colour, rugged tyres and protective parts give the motorcycle a rigorous look to match its urban exploration intentions.

The Lines

Technical Details

ENGINE

  • TRANSMISSION6-speed
  • COOLINGLiquid cooled
  • POWER IN KW32 kW
  • STARTERElectric starter
  • STROKE60 mm
  • BORE89 mm
  • CLUTCHPASC™ antihopping clutch, mechanically operated
  • CO2 EMISSIONS77 g/km
  • DISPLACEMENT373 cm³
  • EMSBosch EMS
  • DESIGN1-cylinder, 4-stroke engine
  • FUEL CONSUMPTION3.6 l/100 km
  • LUBRICATIONForced oil lubrication with 2 oil pumps

CHASSIS

  • WEIGHT (WITHOUT FUEL)152 kg
  • TANK CAPACITY (APPROX.)9.5 l
  • ABStwo channel Bosch 10.1MB
  • FRONT BRAKE DISC DIAMETER300 mm
  • REAR BRAKE DISC DIAMETER230 mm
  • FRONT BRAKEFour-piston radial fixed calliper
  • REAR BRAKESingle-piston floating calliper
  • CHAINX-Ring 5/8 x 1/4″
  • FRAME DESIGNChrome-moly tubular space frame, powder-coated
  • FRONT SUSPENSIONWP APEX 43
  • GROUND CLEARANCE145 mm
  • REAR SUSPENSIONWP APEX – Monoshock
  • SEAT HEIGHT835 mm
  • STEERING HEAD ANGLE65 °
  • SUSPENSION TRAVEL (FRONT)142 mm
  • SUSPENSION TRAVEL (REAR)142 mm
